360° Motion Sensor Switch Photosensitive Control PIR Motion Detector Switch with Time Delay for LED Ceiling Light
360° Motion Sensor Switch Photosensitive Control PIR Motion Detector Switch with Time Delay for LED Ceiling Light
This switch with PIR Motion sensor detector, can be used in corridors, bathrooms, basements, warehouses, garages and other places to achieve automatic control functions. This PIR motion sensor switch has high and stable sensitivity, which can effectively save energy and money for you. Features: 【INTELLIGENT BRIGHTNESS SENSOR】This PIR motion sensor switch can detect human movement and adopts photosensitive control. It will not turn on the light in the daytime or under strong light conditions. You can also choose to turn on the light in any light environment. 【360-DEGREE CONE ANGLE DETECTION RANGE】This PIR motion sensor switch has a 360-degree cone angle detection range and high stable sensitivity, which can effectively save energy and improve efficiency. Specifications: Product model number: TDL-9958R Functional Description : Relay Control Load Operating voltage: 12V Working temperature: -20 °C ~ +50 °C Static power consumption: 0.05W Load power: 120W Load capacity: all kinds of lamps, all kinds of electrical appliances Output Mode: Inductive Output Light control range: 5 Lux ~ 500Lux ± 20% (adjustable sensitivity) Delay range: 30~350s, ± 30% (adjustable delay) Induction mode: passive Sensing angle: 360 degree cone angle Sensing distance: 5-7 m Installation method: suction point installation/ Ceiling installation Size: 898940mm/3.53.51.6inch Package List: 1 Motion Sensor Switch 1 Accessories
- INTELLIGENT BRIGHTNESS SENSOR:This PIR motion sensor switch can adjust the on/off of the wall lamp to detect human movement and adopt photosensitive control. In daylight or under strong light conditions, motion sensor switch will not turn on the lights. You can also choose to turn on the light in any light environment.
- 360-DEGREE CONE ANGLE DETECTION RANGE:The PIR motion sensor wall-mounted sensor switch has a 360-degree cone angle detection range and high stability sensitivity, which can effectively save energy and improve efficiency.
- ADJUSTABLE DELAY:This PIR motion sensor switch has an intelligent sensing function, and pir motion detector will automatically turn off after a delay after the person leaves. After turning 360 degree pir motion switch on within the delay time, if there is no human activity, there will be a period of time to delay the work for a certain period of time and adjust the delay time within an appropriate range.
- WIDE RANGE OF APPLICATIONS:This PIR motion sensor switch PIR motion detector switch has a smart sensing function, and wall mounted sensor detector will automatically turn off after a delay after a person leaves. After turning motion sensor on during the delay time, if there is no human activity, the work will be delayed for a certain period of time and the delay time will be adjusted within an appropriate range.
- TEMPERATURE COMPENSATION:The PIR motion sensor switch 360-degree PIR motion sensor light has high quality and excellent performance. PIR motion sensor switch has a built-in temperature compensation chip that can shorten the collision sensing distance in the entire temperature range.
