{"id":7505525145753,"title":"AEDIKO 10pcs 2A 5V Charge Discharge Integrated Module 3.7V 4.2V for 18650 Lithium Battery Charging Boost Mobile Power Protection PCB Board","handle":"aediko-10pcs-2a-5v-charge-discharge-integrated-module-3-7v-4-2v-for-18650-lithium-battery-charging-boost-mobile-power-protection-pcb-board","description":"\u003ch3\u003eAEDIKO 10pcs 2A 5V Charge Discharge Integrated Module 3.7V 4.2V for 18650 Lithium Battery Charging Boost Mobile Power Protection PCB Board\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures:Charging Voltage: DC 4.5V-5.5V (DC 5V Recommended)Charging Current:\n0-2.1ACharging Quiescent Current: 100uAFull Voltage: 4.2V+ -1%Discharge\nCurrent: 0-2.4ADischarge Quiescent Current: 50uADischarge Efficiency: up to\n96%Output Voltage: 5VOutput Current: 0-2.4AAmbient Temperature: -20℃ to +\n85℃Size : 25 16 4mmAllow Discharge While Charging. (Note: At this time\nOutput Voltage 4.7 \/ 5V)Pins:VIN: Charge port positive input +GND: Charger\nNegative Input -BAT: Lithium Battery +GND: Lithium Battery -GND: Output\nnegative output -OUT: Output Positive Output +KEY: Output Enable Trigger Port\n(Low Pulse Trigger) Package Contents:10x 2A 5V Lithium Battery Charging\nProtection Module\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e2A 5V Lithium Battery Charging Protection Module:Output Voltage: 5V; Charging Current: 0-2.1A;Charging Voltage: DC 4.5V-5.5V (DC 5V Recommended)\u003c\/li\u003e\n \u003cli\u003eMCU Users: if You Accept a Small Load KEY Can be Connected to the Microcontroller about 20s to Provide a Low Level Allows the Module to Continue Working. Trigger Mode: Low Level Trigger (Ground)\u003c\/li\u003e\n \u003cli\u003eProtection Functions: 4 in 1 Charging \/ Discharging \/ Lithium Battery Protection \/ Battery Level Indicator Module.Lithium Battery Protection Function:Over-Current Protection,Over-Voltage Protection, Over-Temperature Protection, Short Circuit Protection\u003c\/li\u003e\n \u003cli\u003eNOTE:The First Time the Load is Connected, Output is Automatically Turned On. If the Load is Less than 50MA, the Output will be Automatically Turned Off after 30s; if the Load is Greater than 50MA, the Output Will be Automatically Turned On\u003c\/li\u003e\n \u003cli\u003eApplication:2A 5V Module Widely Used for Mobile Power, Car Charging Retrofit,Driving Recorder Power Supply and Portable Devices Such As Mobile Phones and Tablets\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n","published_at":"2022-08-31T03:24:39+10:00","created_at":"2022-08-31T03:24:47+10:00","vendor":"AEDIKO","type":"Communication Integrated Circuits","tags":["industrial2"],"price":11400,"price_min":11400,"price_max":11400,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42549321793689,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B09JZFXD1X","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"AEDIKO 10pcs 2A 5V Charge Discharge Integrated Module 3.7V 4.2V for 18650 Lithium Battery Charging Boost Mobile Power Protection PCB Board","public_title":null,"options":["Default Title"],"price":11400,"weight":102,"compare_at_price":null,"inventory_management":null,"barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/products\/B09JZFXD1X.jpg?v=1661958015","\/\/soundstores.net\/cdn\/shop\/products\/71PKd8x1AzL.jpg?v=1661880287","\/\/soundstores.net\/cdn\/shop\/products\/71WY2l0fx-L.jpg?v=1661880287","\/\/soundstores.net\/cdn\/shop\/products\/61yP7DMCe3L.jpg?v=1661880287","\/\/soundstores.net\/cdn\/shop\/products\/61MF6iOL2jL.jpg?v=1661880287","\/\/soundstores.net\/cdn\/shop\/products\/71qgxRsW_DL.jpg?v=1661880287"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/products\/B09JZFXD1X.jpg?v=1661958015","options":["Title"],"media":[{"alt":null,"id":27717681840281,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/B09JZFXD1X.jpg?v=1661958015"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/B09JZFXD1X.jpg?v=1661958015","width":1600},{"alt":null,"id":27710121181337,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/71PKd8x1AzL.jpg?v=1661880287"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/71PKd8x1AzL.jpg?v=1661880287","width":1600},{"alt":null,"id":27710121214105,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/71WY2l0fx-L.jpg?v=1661880287"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/71WY2l0fx-L.jpg?v=1661880287","width":1600},{"alt":null,"id":27710121246873,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61yP7DMCe3L.jpg?v=1661880287"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61yP7DMCe3L.jpg?v=1661880287","width":1600},{"alt":null,"id":27710121279641,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61MF6iOL2jL.jpg?v=1661880287"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61MF6iOL2jL.jpg?v=1661880287","width":1600},{"alt":null,"id":27710121312409,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/71qgxRsW_DL.jpg?v=1661880287"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/71qgxRsW_DL.jpg?v=1661880287","width":1600}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eAEDIKO 10pcs 2A 5V Charge Discharge Integrated Module 3.7V 4.2V for 18650 Lithium Battery Charging Boost Mobile Power Protection PCB Board\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures:Charging Voltage: DC 4.5V-5.5V (DC 5V Recommended)Charging Current:\n0-2.1ACharging Quiescent Current: 100uAFull Voltage: 4.2V+ -1%Discharge\nCurrent: 0-2.4ADischarge Quiescent Current: 50uADischarge Efficiency: up to\n96%Output Voltage: 5VOutput Current: 0-2.4AAmbient Temperature: -20℃ to +\n85℃Size : 25 16 4mmAllow Discharge While Charging. (Note: At this time\nOutput Voltage 4.7 \/ 5V)Pins:VIN: Charge port positive input +GND: Charger\nNegative Input -BAT: Lithium Battery +GND: Lithium Battery -GND: Output\nnegative output -OUT: Output Positive Output +KEY: Output Enable Trigger Port\n(Low Pulse Trigger) Package Contents:10x 2A 5V Lithium Battery Charging\nProtection Module\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e2A 5V Lithium Battery Charging Protection Module:Output Voltage: 5V; Charging Current: 0-2.1A;Charging Voltage: DC 4.5V-5.5V (DC 5V Recommended)\u003c\/li\u003e\n \u003cli\u003eMCU Users: if You Accept a Small Load KEY Can be Connected to the Microcontroller about 20s to Provide a Low Level Allows the Module to Continue Working. Trigger Mode: Low Level Trigger (Ground)\u003c\/li\u003e\n \u003cli\u003eProtection Functions: 4 in 1 Charging \/ Discharging \/ Lithium Battery Protection \/ Battery Level Indicator Module.Lithium Battery Protection Function:Over-Current Protection,Over-Voltage Protection, Over-Temperature Protection, Short Circuit Protection\u003c\/li\u003e\n \u003cli\u003eNOTE:The First Time the Load is Connected, Output is Automatically Turned On. If the Load is Less than 50MA, the Output will be Automatically Turned Off after 30s; if the Load is Greater than 50MA, the Output Will be Automatically Turned On\u003c\/li\u003e\n \u003cli\u003eApplication:2A 5V Module Widely Used for Mobile Power, Car Charging Retrofit,Driving Recorder Power Supply and Portable Devices Such As Mobile Phones and Tablets\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n"}
