{"id":7494740672665,"title":"Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V","handle":"boffdock-45-5-mfd-capacitor-5-45-5-uf-370-440-vac-cbb65-round-dual-run-capacitor-for-air-conditioner-heat-pump-condenser-fan-start-5-years-warranty-45-5uf-370-440v","description":"\u003ch3\u003eBoffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eWELL PACKAGED Boffdock AC Capacitor 50\/60 45+5 MFD±5% 45\/5 uF 370\/440 VAC\nCBB65 Round Dual Run Capacitor for Condenser Straight Cool or Heat Pump Air\nConditioner,Heat Pump Condenser,Fan Start, Pool pumps,Furnaces,45\/5 Microfarad\n- AC Motor Run,HVAC and Fan-5 Years WarrantyDescriptionCapacitance tolerance:\n± 5% Rated voltage: 370V \/ 450VACWorking Temperature(TW): -40 ℃ to 70 ℃ Rated\nFrequency(fn): 50\/60HzDielectric dissipation: ≤0.002 100HzRelative humidity:\n≤95%Dielectric Material: PolypropyleneEncapsulation method: AluminumTerminal\nconductor: CopperTest standard: IEC60252Flammability rating: UL94V-0Explosion\nproof rating: S2The 45\/5 uf round dual run capacitor for ac combines two\ncapacitors into one unit. AC capacitor will power a compressor motor and a fan\nmotor, and has three terminals on the top. They are labeled \"HERM\" for the\ncompressor motor, \"FAN\" for the fan, and \"C\" for the common line.Safety\nmeasure:When replacing a capacitor always be sure to turn off the power to the\nair conditioning unit and place a screw driver between the terminals of the\ncapacitor to release any stored charge. In order to allow a correct working of\nthe safety device and to assure a sufficient electric insulation, a room of\n0.59inch\/15mm.Replacement for\n97F9895,Z97F995,97F9895BZ3,27L880,TRCD455,TRCFD455, PRCFD455,27L889,\n97F9851,97F9851S,12788,RC0114,Z97F9895,97F9895,HC98JA046,TT-\nCAP-45\/5\/440R,HC98KA046 , CAP050450440RT ,TP-CAP-45\/5\/440R ,\nHCKS450D050R440Z,62\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUL Approved and ROHS Compliant AC Capacitor. Specification:1.97\" in Diameter by 4.92\" in Height.\u003c\/li\u003e\n \u003cli\u003e45+5 uf or MFD 370\/440 Volt AC Compressor Capacitor. Working Temperature(TW): -104F\/-40 C to +158F\/70 C.\u003c\/li\u003e\n \u003cli\u003eEnvironmental friendly vegetable oil filled,Cylindrical aluminum outer shell, With pressure-isolation explosion-proof device.\u003c\/li\u003e\n \u003cli\u003eBuilt to the TOUGHEST USA standards for AC motor run capacitors including EIA-456-A and IEC 60252-1:2001\u003c\/li\u003e\n \u003cli\u003eWarranty policy: 5 year 100% Guarantee.\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n","published_at":"2022-08-20T00:08:26+10:00","created_at":"2022-08-20T00:08:34+10:00","vendor":"Boffdock","type":"Capacitors","tags":["industrial2"],"price":16100,"price_min":16100,"price_max":16100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42503043645593,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B09B7RJL1N","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V","public_title":null,"options":["Default Title"],"price":16100,"weight":331,"compare_at_price":null,"inventory_management":null,"barcode":"BIS002","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/products\/B09B7RJL1N.jpg?v=1660923286","\/\/soundstores.net\/cdn\/shop\/products\/71Dvz0snyIL.jpg?v=1660918114","\/\/soundstores.net\/cdn\/shop\/products\/71OYJhOAJHL.jpg?v=1660918114","\/\/soundstores.net\/cdn\/shop\/products\/718AcSs1xgL.jpg?v=1660918114","\/\/soundstores.net\/cdn\/shop\/products\/51Fjy63_oLL.jpg?v=1660918114","\/\/soundstores.net\/cdn\/shop\/products\/61YExzw_0aL.jpg?v=1660918114"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/products\/B09B7RJL1N.jpg?v=1660923286","options":["Title"],"media":[{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641800720537,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/B09B7RJL1N.jpg?v=1660923286"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/B09B7RJL1N.jpg?v=1660923286","width":1600},{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641452036249,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/71Dvz0snyIL.jpg?v=1660918114"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/71Dvz0snyIL.jpg?v=1660918114","width":1600},{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641452069017,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/71OYJhOAJHL.jpg?v=1660918114"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/71OYJhOAJHL.jpg?v=1660918114","width":1600},{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641452101785,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/718AcSs1xgL.jpg?v=1660918114"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/718AcSs1xgL.jpg?v=1660918114","width":1600},{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641452134553,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/51Fjy63_oLL.jpg?v=1660918114"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/51Fjy63_oLL.jpg?v=1660918114","width":1600},{"alt":"[AUSTRALIA] - Boffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty 45+5UF-370\/440V ","id":27641452167321,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61YExzw_0aL.jpg?v=1660918114"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61YExzw_0aL.jpg?v=1660918114","width":1600}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eBoffdock 45+5 MFD Capacitor ±5% 45\/5 uF 370\/440 VAC CBB65 Round Dual Run Capacitor for Air Conditioner,Heat Pump Condenser,Fan Start- 5 Years Warranty\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eWELL PACKAGED Boffdock AC Capacitor 50\/60 45+5 MFD±5% 45\/5 uF 370\/440 VAC\nCBB65 Round Dual Run Capacitor for Condenser Straight Cool or Heat Pump Air\nConditioner,Heat Pump Condenser,Fan Start, Pool pumps,Furnaces,45\/5 Microfarad\n- AC Motor Run,HVAC and Fan-5 Years WarrantyDescriptionCapacitance tolerance:\n± 5% Rated voltage: 370V \/ 450VACWorking Temperature(TW): -40 ℃ to 70 ℃ Rated\nFrequency(fn): 50\/60HzDielectric dissipation: ≤0.002 100HzRelative humidity:\n≤95%Dielectric Material: PolypropyleneEncapsulation method: AluminumTerminal\nconductor: CopperTest standard: IEC60252Flammability rating: UL94V-0Explosion\nproof rating: S2The 45\/5 uf round dual run capacitor for ac combines two\ncapacitors into one unit. AC capacitor will power a compressor motor and a fan\nmotor, and has three terminals on the top. They are labeled \"HERM\" for the\ncompressor motor, \"FAN\" for the fan, and \"C\" for the common line.Safety\nmeasure:When replacing a capacitor always be sure to turn off the power to the\nair conditioning unit and place a screw driver between the terminals of the\ncapacitor to release any stored charge. In order to allow a correct working of\nthe safety device and to assure a sufficient electric insulation, a room of\n0.59inch\/15mm.Replacement for\n97F9895,Z97F995,97F9895BZ3,27L880,TRCD455,TRCFD455, PRCFD455,27L889,\n97F9851,97F9851S,12788,RC0114,Z97F9895,97F9895,HC98JA046,TT-\nCAP-45\/5\/440R,HC98KA046 , CAP050450440RT ,TP-CAP-45\/5\/440R ,\nHCKS450D050R440Z,62\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUL Approved and ROHS Compliant AC Capacitor. Specification:1.97\" in Diameter by 4.92\" in Height.\u003c\/li\u003e\n \u003cli\u003e45+5 uf or MFD 370\/440 Volt AC Compressor Capacitor. Working Temperature(TW): -104F\/-40 C to +158F\/70 C.\u003c\/li\u003e\n \u003cli\u003eEnvironmental friendly vegetable oil filled,Cylindrical aluminum outer shell, With pressure-isolation explosion-proof device.\u003c\/li\u003e\n \u003cli\u003eBuilt to the TOUGHEST USA standards for AC motor run capacitors including EIA-456-A and IEC 60252-1:2001\u003c\/li\u003e\n \u003cli\u003eWarranty policy: 5 year 100% Guarantee.\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n"}
