{"id":8750775763097,"title":"DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter","handle":"dtxmx-flysky-receiver-fs-ia6b-2-4g-afhds-2a-6channels-support-pwm-ppm-i-bus-output-compatible-flysky-fs-i6-fs-i6x-fs-i6s-and-i10-rc-radio-transmitter","description":"\u003ch3\u003eDTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eHow to bind with FLYSKY transmitter(fs-i6,fs-i6x)? 1, Connect the supplied\r\nbind cable to the B\/VCC port on the receiver. 2, Insert power into any other\r\nport. 3, Hold the \"BIND KEY\" while powering on the transmitter to enter bind\r\nmode. 4, Remove the power and bind cable from the receiver. Then connect the\r\npower cable to the B\/VCC port. 5, Check the servos' operation. If anything\r\ndoes not work as expected, restart this procedure from the beginning. FS-IA6B\r\nSpecification: Item Name: FS-iA6B Channel: 6 Frequency Range: 2.4055--2.475GHZ\r\nbrand Width Number: 140 Transmitting Power: ≤ 20dBm RF Receiver Sensitivity:\r\n-105dbm 2.4G Mode: The second generation of an enhanced version of the\r\nautomatic FM digital system Encoding: GFSK Antenna Length: 26mm 2 (dual\r\nantenna) Input Power: 4.0-8.5V DC Dimension: 47 x 26.2 x 15mm Weight: 14.9g\r\ni-Bus \/PPM\/PWM Interface: Yes Data Acquisition Interface: Yes Model Type:\r\nAirplane \/ Glider \/ Helicopter Package Included: 1x Flysky fs-ia6b receiver 1x\r\nBind plug\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eIt is reliable, operates with 2.4 GHz AFHDS 2A signal, safe and steady and does not interfere with.\u003c\/li\u003e\r\n \u003cli\u003eSupport PPM output, single wire connection flight control, with iBus interface, scalable channel.\u003c\/li\u003e\r\n \u003cli\u003eBetter compatibility, it can be compatible for FS-i4, FS-i6, FS-i6X,FS-i6S,FS-i10 variety of transmitters, reduce your trouble.\u003c\/li\u003e\r\n \u003cli\u003e2.4G mode is an improved version of the second generation digital automatic FM system with six channels to provide better signal.\u003c\/li\u003e\r\n \u003cli\u003eApplicable to aircraft \/ glider \/ helicopter, with I-Bus interface and data acquisition interface.\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2026-05-18T14:17:07+10:00","created_at":"2026-05-18T14:17:03+10:00","vendor":"DTXMX","type":"Radio Receivers","tags":["sound_Apr2026"],"price":11500,"price_min":11500,"price_max":11500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":47539389431961,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0B5RL8NQL","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter","public_title":null,"options":["Default Title"],"price":11500,"weight":18,"compare_at_price":null,"inventory_management":"shopify","barcode":"FS-iA6B","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/51duVaW5tfL.jpg?v=1779077826","\/\/soundstores.net\/cdn\/shop\/files\/61pjcCqXPqL.jpg?v=1779077826","\/\/soundstores.net\/cdn\/shop\/files\/616I0v4ZHNL.jpg?v=1779077826","\/\/soundstores.net\/cdn\/shop\/files\/71xT7mFlyRL.jpg?v=1779077826","\/\/soundstores.net\/cdn\/shop\/files\/510gh7zYBfL.jpg?v=1779077826"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/51duVaW5tfL.jpg?v=1779077826","options":["Title"],"media":[{"alt":"[AUSTRALIA] - DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter ","id":36413833937049,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51duVaW5tfL.jpg?v=1779077826"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51duVaW5tfL.jpg?v=1779077826","width":1200},{"alt":"[AUSTRALIA] - DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter ","id":36413833969817,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61pjcCqXPqL.jpg?v=1779077826"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61pjcCqXPqL.jpg?v=1779077826","width":1200},{"alt":"[AUSTRALIA] - DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter ","id":36413834002585,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/616I0v4ZHNL.jpg?v=1779077826"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/616I0v4ZHNL.jpg?v=1779077826","width":1200},{"alt":"[AUSTRALIA] - DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter ","id":36413834035353,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/71xT7mFlyRL.jpg?v=1779077826"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/71xT7mFlyRL.jpg?v=1779077826","width":1200},{"alt":"[AUSTRALIA] - DTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter ","id":36413834068121,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/510gh7zYBfL.jpg?v=1779077826"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/510gh7zYBfL.jpg?v=1779077826","width":1200}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eDTXMX Flysky Receiver FS-iA6B 2.4G AFHDS 2A 6Channels Support PWM\/PPM\/i-Bus Output Compatible Flysky FS-i6 FS-i6X FS-i6S and i10 RC Radio Transmitter\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eHow to bind with FLYSKY transmitter(fs-i6,fs-i6x)? 1, Connect the supplied\r\nbind cable to the B\/VCC port on the receiver. 2, Insert power into any other\r\nport. 3, Hold the \"BIND KEY\" while powering on the transmitter to enter bind\r\nmode. 4, Remove the power and bind cable from the receiver. Then connect the\r\npower cable to the B\/VCC port. 5, Check the servos' operation. If anything\r\ndoes not work as expected, restart this procedure from the beginning. FS-IA6B\r\nSpecification: Item Name: FS-iA6B Channel: 6 Frequency Range: 2.4055--2.475GHZ\r\nbrand Width Number: 140 Transmitting Power: ≤ 20dBm RF Receiver Sensitivity:\r\n-105dbm 2.4G Mode: The second generation of an enhanced version of the\r\nautomatic FM digital system Encoding: GFSK Antenna Length: 26mm 2 (dual\r\nantenna) Input Power: 4.0-8.5V DC Dimension: 47 x 26.2 x 15mm Weight: 14.9g\r\ni-Bus \/PPM\/PWM Interface: Yes Data Acquisition Interface: Yes Model Type:\r\nAirplane \/ Glider \/ Helicopter Package Included: 1x Flysky fs-ia6b receiver 1x\r\nBind plug\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eIt is reliable, operates with 2.4 GHz AFHDS 2A signal, safe and steady and does not interfere with.\u003c\/li\u003e\r\n \u003cli\u003eSupport PPM output, single wire connection flight control, with iBus interface, scalable channel.\u003c\/li\u003e\r\n \u003cli\u003eBetter compatibility, it can be compatible for FS-i4, FS-i6, FS-i6X,FS-i6S,FS-i10 variety of transmitters, reduce your trouble.\u003c\/li\u003e\r\n \u003cli\u003e2.4G mode is an improved version of the second generation digital automatic FM system with six channels to provide better signal.\u003c\/li\u003e\r\n \u003cli\u003eApplicable to aircraft \/ glider \/ helicopter, with I-Bus interface and data acquisition interface.\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
