{"id":8532510539929,"title":"Hailege 2pcs INA226 I2C IIC Bidirectional Current Monitoring Sensor Performance Monitor Sensor with Alarm Function","handle":"hailege-2pcs-ina226-i2c-iic-bidirectional-current-monitoring-sensor-performance-monitor-sensor-with-alarm-function","description":"\u003ch3\u003eHailege 2pcs INA226 I2C IIC Bidirectional Current Monitoring Sensor Performance Monitor Sensor with Alarm Function\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: Voltage: 0-36V Indicates current, voltage and power High Accuracy:\n0.1% gain error (max.) 10? V offset (max.) Configurable averaging options 16\nprogrammable addresses. Operates from 2.7 V to 5.5 V power supply. 10-pin, DGS\n(VSSOP) housing Pin Out: VBUS: bus voltage input. SDA\/SCL: IIC bus data and\nclock signal lines Alarm: multi-function alarm output. A0\/A1: IIC address line\nIN+\/IN-: non-inverting analog input, inverting analog input Description: The\nINA226 is a power shunt and performance monitor with an I2C or SMBUS\ncompatible interface. The device monitors both a shunt voltage drop and the\nbus supply voltage. Programmable calibration values, conversion times and\naveraging combined with an internal multiplier allow direct reading of current\nirradiation and power in watts. The INA226 measures current at common mode bus\nvoltages, which can vary from 0V to 36V regardless of supply voltage. The\ndevice is powered by a single 2.7V to 5.5V supply, which is a typical 330? A\nof the supply current. The device is specified over the operating temperature\nrange between 0.0 and 125.5 μm and has up to 16 programmable addresses on the\nI2C compatible interface. Box contents: 2 x INA226 IIC I2C bidirectional\ncurrent monitoring sensors\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eCan be applied to servers, telecommunications equipment, power management, battery chargers and power supplies\u003c\/li\u003e\n \u003cli\u003eBidirectional current monitoring sensor INA226 IIC I2C\u003c\/li\u003e\n \u003cli\u003eHigh Accuracy 16 Programmable Addresses 10 Pin DGS (VSSOP) Housing\u003c\/li\u003e\n \u003cli\u003eWe offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-09-26T00:51:36+10:00","created_at":"2025-09-26T00:51:33+10:00","vendor":"Hailege","type":"Current Sensors","tags":["industryDE_Sep2025"],"price":11400,"price_min":11400,"price_max":11400,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45746943099033,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0CJY2WMNY","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Hailege 2pcs INA226 I2C IIC Bidirectional Current Monitoring Sensor Performance Monitor Sensor with Alarm Function","public_title":null,"options":["Default Title"],"price":11400,"weight":20,"compare_at_price":null,"inventory_management":"shopify","barcode":"H-1-1791","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/de-B0CJY2WMNY.jpg?v=1775751028","\/\/soundstores.net\/cdn\/shop\/files\/51uTvsmb25L.jpg?v=1758811895","\/\/soundstores.net\/cdn\/shop\/files\/51SusDGziML.jpg?v=1758811895","\/\/soundstores.net\/cdn\/shop\/files\/51Bcwstz4-L.jpg?v=1758811895","\/\/soundstores.net\/cdn\/shop\/files\/61LH9lgKSXL.jpg?v=1758811895","\/\/soundstores.net\/cdn\/shop\/files\/51BHV-8c_EL.jpg?v=1758811895","\/\/soundstores.net\/cdn\/shop\/files\/51c0Ga4AmdL_0ce7c719-2247-4c25-86f5-5df265c328a5.jpg?v=1758811895"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0CJY2WMNY.jpg?v=1775751028","options":["Title"],"media":[{"alt":null,"id":34642660032665,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1050,"width":1050,"src":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0CJY2WMNY.jpg?v=1775751028"},"aspect_ratio":1.0,"height":1050,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0CJY2WMNY.jpg?v=1775751028","width":1050},{"alt":null,"id":34642660065433,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1050,"width":1050,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51uTvsmb25L.jpg?v=1758811895"},"aspect_ratio":1.0,"height":1050,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51uTvsmb25L.jpg?v=1758811895","width":1050},{"alt":null,"id":34642660098201,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1050,"width":1050,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51SusDGziML.jpg?v=1758811895"},"aspect_ratio":1.0,"height":1050,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51SusDGziML.jpg?v=1758811895","width":1050},{"alt":null,"id":34642660130969,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1050,"width":1050,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51Bcwstz4-L.jpg?v=1758811895"},"aspect_ratio":1.0,"height":1050,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51Bcwstz4-L.jpg?v=1758811895","width":1050},{"alt":null,"id":34642660163737,"position":5,"preview_image":{"aspect_ratio":1.727,"height":579,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61LH9lgKSXL.jpg?v=1758811895"},"aspect_ratio":1.727,"height":579,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61LH9lgKSXL.jpg?v=1758811895","width":1000},{"alt":null,"id":34642660196505,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1050,"width":1050,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51BHV-8c_EL.jpg?v=1758811895"},"aspect_ratio":1.0,"height":1050,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51BHV-8c_EL.jpg?v=1758811895","width":1050},{"alt":null,"id":34642660229273,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1100,"width":1100,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51c0Ga4AmdL_0ce7c719-2247-4c25-86f5-5df265c328a5.jpg?v=1758811895"},"aspect_ratio":1.0,"height":1100,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51c0Ga4AmdL_0ce7c719-2247-4c25-86f5-5df265c328a5.jpg?v=1758811895","width":1100}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHailege 2pcs INA226 I2C IIC Bidirectional Current Monitoring Sensor Performance Monitor Sensor with Alarm Function\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: Voltage: 0-36V Indicates current, voltage and power High Accuracy:\n0.1% gain error (max.) 10? V offset (max.) Configurable averaging options 16\nprogrammable addresses. Operates from 2.7 V to 5.5 V power supply. 10-pin, DGS\n(VSSOP) housing Pin Out: VBUS: bus voltage input. SDA\/SCL: IIC bus data and\nclock signal lines Alarm: multi-function alarm output. A0\/A1: IIC address line\nIN+\/IN-: non-inverting analog input, inverting analog input Description: The\nINA226 is a power shunt and performance monitor with an I2C or SMBUS\ncompatible interface. The device monitors both a shunt voltage drop and the\nbus supply voltage. Programmable calibration values, conversion times and\naveraging combined with an internal multiplier allow direct reading of current\nirradiation and power in watts. The INA226 measures current at common mode bus\nvoltages, which can vary from 0V to 36V regardless of supply voltage. The\ndevice is powered by a single 2.7V to 5.5V supply, which is a typical 330? A\nof the supply current. The device is specified over the operating temperature\nrange between 0.0 and 125.5 μm and has up to 16 programmable addresses on the\nI2C compatible interface. Box contents: 2 x INA226 IIC I2C bidirectional\ncurrent monitoring sensors\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eCan be applied to servers, telecommunications equipment, power management, battery chargers and power supplies\u003c\/li\u003e\n \u003cli\u003eBidirectional current monitoring sensor INA226 IIC I2C\u003c\/li\u003e\n \u003cli\u003eHigh Accuracy 16 Programmable Addresses 10 Pin DGS (VSSOP) Housing\u003c\/li\u003e\n \u003cli\u003eWe offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.\u003c\/li\u003e\n \u003c\/ul\u003e"}
