{"id":7503876554905,"title":"Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires","handle":"heschen-m18-capacitive-proximity-sensor-switch-non-shield-type-ljc18a3-b-z-ax-detection-10mm-10-30vdc-200ma-npn-normally-closednc-3-wires","description":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(6-36V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:300mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 10mm10%;Set distance:0-8mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: NPN Normally Closed(NC),Non-Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30VDC\u003c\/li\u003e\n \u003cli\u003eCable Length: 50\"(127cm)\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n","published_at":"2022-08-30T03:51:19+10:00","created_at":"2022-08-30T03:51:27+10:00","vendor":"Heschen","type":"Proximity Sensors","tags":["industrial2"],"price":10400,"price_min":10400,"price_max":10400,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42544473342105,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0719Q6NV7","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires","public_title":null,"options":["Default Title"],"price":10400,"weight":110,"compare_at_price":null,"inventory_management":null,"barcode":"HS-LJC18A3-B-Z\/AX","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/products\/B0719Q6NV7.jpg?v=1661873850","\/\/soundstores.net\/cdn\/shop\/products\/61YEa9cWLmL_53a81fda-01fc-4976-b409-0342e21983b6.jpg?v=1661795487","\/\/soundstores.net\/cdn\/shop\/products\/61d7wU5iB-L_7c2a50c5-3aad-4e0c-8b47-40cee22826ca.jpg?v=1661795487","\/\/soundstores.net\/cdn\/shop\/products\/61-Xh4cz-mL_4795b6e1-3b11-44c5-93bb-86f54a8db691.jpg?v=1661795487","\/\/soundstores.net\/cdn\/shop\/products\/61kw0nysU1L.jpg?v=1661795487","\/\/soundstores.net\/cdn\/shop\/products\/610010RoM8L.jpg?v=1661795487","\/\/soundstores.net\/cdn\/shop\/products\/61lQEkWhp8L_5144f163-64c5-4898-af21-c2e1b49df97b.jpg?v=1661795487"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/products\/B0719Q6NV7.jpg?v=1661873850","options":["Title"],"media":[{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27709602988185,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/B0719Q6NV7.jpg?v=1661873850"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/B0719Q6NV7.jpg?v=1661873850","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121431193,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61YEa9cWLmL_53a81fda-01fc-4976-b409-0342e21983b6.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61YEa9cWLmL_53a81fda-01fc-4976-b409-0342e21983b6.jpg?v=1661795487","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121463961,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61d7wU5iB-L_7c2a50c5-3aad-4e0c-8b47-40cee22826ca.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61d7wU5iB-L_7c2a50c5-3aad-4e0c-8b47-40cee22826ca.jpg?v=1661795487","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121496729,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61-Xh4cz-mL_4795b6e1-3b11-44c5-93bb-86f54a8db691.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61-Xh4cz-mL_4795b6e1-3b11-44c5-93bb-86f54a8db691.jpg?v=1661795487","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121529497,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61kw0nysU1L.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61kw0nysU1L.jpg?v=1661795487","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121562265,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/610010RoM8L.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/610010RoM8L.jpg?v=1661795487","width":1300},{"alt":"[AUSTRALIA] - Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires ","id":27702121595033,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/soundstores.net\/cdn\/shop\/products\/61lQEkWhp8L_5144f163-64c5-4898-af21-c2e1b49df97b.jpg?v=1661795487"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/products\/61lQEkWhp8L_5144f163-64c5-4898-af21-c2e1b49df97b.jpg?v=1661795487","width":1300}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/AX Detection 10mm 10-30VDC 200mA NPN Normally Closed(NC) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(6-36V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:300mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 10mm10%;Set distance:0-8mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: NPN Normally Closed(NC),Non-Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30VDC\u003c\/li\u003e\n \u003cli\u003eCable Length: 50\"(127cm)\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n"}
