{"id":8556289261721,"title":"High Power 24 Channel RGB 3A\/CH DMX512 Controller Led Decoder Dimmer 500Hz Flicker Free Smoother Dimming DMX Signal Indicator Flashes Function DC 5V-24V","handle":"high-power-24-channel-rgb-3a-ch-dmx512-controller-led-decoder-dimmer-500hz-flicker-free-smoother-dimming-dmx-signal-indicator-flashes-function-dc-5v-24v","description":"\u003ch3\u003eHigh Power 24 Channel RGB 3A\/CH DMX512 Controller Led Decoder Dimmer 500Hz Flicker Free Smoother Dimming DMX Signal Indicator Flashes Function DC 5V-24V\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e\" 24CH RGB DMX decoding driver converts a DMX512\/1990\r\ninput to PWM output with 256 different levels output per channel. With\r\nimproved firmware, it provides flicker free and smoother dimming. Power input:\r\nDC 5V – 24V Channels: 24 (8 groups of 3 channels – ideal for RGB) Output\r\nrating: 3A per channel Input: DMX512 Plug-in terminal blocks for easy\r\nconnections Operating temperature: -20 – 50°C imensions: 145 x 78 x 31mm (145\r\nx 109 x 31mm including connectors) The DMX decoder has 24 PWM outputs that are\r\ncontrolled by a DMX512 input. The DMX channel is set by DIP switches on the\r\nside of the device. There are 10 built-in programs which can be used for\r\ntesting or for simple displays. This device has two DC power inputs (one for\r\neach set of 12 outputs), allowing the outputs to be split across two power\r\nsources for high-current applications. \"\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003e24 output channels, 3A per channel arranged in groups of three (ideal for RGB LEDs).\u003c\/li\u003e\r\n \u003cli\u003e0 - 100% smooth brightness control, 256 steps per channel.\u003c\/li\u003e\r\n \u003cli\u003eUniversal standard DMX512 input protocol; addresses can be set by DIP switch.\u003c\/li\u003e\r\n \u003cli\u003eWorking voltage from DC 5V - 24V. Power loss memory function\u003c\/li\u003e\r\n \u003cli\u003e10 built-in programs, 8 speeds.\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-25T11:47:22+11:00","created_at":"2025-10-25T11:47:18+11:00","vendor":"Colorful-USA","type":"Lighting Accessories","tags":["music_selected_Oct2025"],"price":27100,"price_min":27100,"price_max":27100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45826576089241,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B01CCBG1SO","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"High Power 24 Channel RGB 3A\/CH DMX512 Controller Led Decoder Dimmer 500Hz Flicker Free Smoother Dimming DMX Signal Indicator Flashes Function DC 5V-24V","public_title":null,"options":["Default Title"],"price":27100,"weight":400,"compare_at_price":null,"inventory_management":"shopify","barcode":"707837311377","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/B01CCBG1SO.jpg?v=1775758882","\/\/soundstores.net\/cdn\/shop\/files\/91bldfO3icL.jpg?v=1761353241","\/\/soundstores.net\/cdn\/shop\/files\/71JIUXaAmuL.jpg?v=1761353241","\/\/soundstores.net\/cdn\/shop\/files\/61Qjtsn21FL.jpg?v=1761353240","\/\/soundstores.net\/cdn\/shop\/files\/61O7HGTizfL.jpg?v=1761353240","\/\/soundstores.net\/cdn\/shop\/files\/61uigccltTL.jpg?v=1761353241"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/B01CCBG1SO.jpg?v=1775758882","options":["Title"],"media":[{"alt":null,"id":34928388145305,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/B01CCBG1SO.jpg?v=1775758882"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/B01CCBG1SO.jpg?v=1775758882","width":1000},{"alt":null,"id":34928388178073,"position":2,"preview_image":{"aspect_ratio":0.717,"height":2560,"width":1835,"src":"\/\/soundstores.net\/cdn\/shop\/files\/91bldfO3icL.jpg?v=1761353241"},"aspect_ratio":0.717,"height":2560,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/91bldfO3icL.jpg?v=1761353241","width":1835},{"alt":null,"id":34928388210841,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/71JIUXaAmuL.jpg?v=1761353241"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/71JIUXaAmuL.jpg?v=1761353241","width":1000},{"alt":null,"id":34928388243609,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61Qjtsn21FL.jpg?v=1761353240"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61Qjtsn21FL.jpg?v=1761353240","width":1000},{"alt":null,"id":34928388276377,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61O7HGTizfL.jpg?v=1761353240"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61O7HGTizfL.jpg?v=1761353240","width":1000},{"alt":null,"id":34928388309145,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61uigccltTL.jpg?v=1761353241"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61uigccltTL.jpg?v=1761353241","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHigh Power 24 Channel RGB 3A\/CH DMX512 Controller Led Decoder Dimmer 500Hz Flicker Free Smoother Dimming DMX Signal Indicator Flashes Function DC 5V-24V\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e\" 24CH RGB DMX decoding driver converts a DMX512\/1990\r\ninput to PWM output with 256 different levels output per channel. With\r\nimproved firmware, it provides flicker free and smoother dimming. Power input:\r\nDC 5V – 24V Channels: 24 (8 groups of 3 channels – ideal for RGB) Output\r\nrating: 3A per channel Input: DMX512 Plug-in terminal blocks for easy\r\nconnections Operating temperature: -20 – 50°C imensions: 145 x 78 x 31mm (145\r\nx 109 x 31mm including connectors) The DMX decoder has 24 PWM outputs that are\r\ncontrolled by a DMX512 input. The DMX channel is set by DIP switches on the\r\nside of the device. There are 10 built-in programs which can be used for\r\ntesting or for simple displays. This device has two DC power inputs (one for\r\neach set of 12 outputs), allowing the outputs to be split across two power\r\nsources for high-current applications. \"\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003e24 output channels, 3A per channel arranged in groups of three (ideal for RGB LEDs).\u003c\/li\u003e\r\n \u003cli\u003e0 - 100% smooth brightness control, 256 steps per channel.\u003c\/li\u003e\r\n \u003cli\u003eUniversal standard DMX512 input protocol; addresses can be set by DIP switch.\u003c\/li\u003e\r\n \u003cli\u003eWorking voltage from DC 5V - 24V. Power loss memory function\u003c\/li\u003e\r\n \u003cli\u003e10 built-in programs, 8 speeds.\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
