{"id":8532526530713,"title":"Mean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt Single","handle":"mean-well-hdr-30-24-din-rail-power-supply-din-rail-24-vdc-1-5-a-36-watt-single","description":"\u003ch3\u003eMean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSingle-phase MEANWELL switching power supply series HDR-30, primarily clocked\nfor DIN rail mounting in plastic housing. Can be mounted directly on the DIN\nrail. Closed design, touch-protected screw connections. Universal input.\nOverload protection thanks to current limitation, auto recovery. Protected\nagainst short circuit, overload, overvoltage. Compact size: 2 TE (DIN\nEN43880). Low idle power of only 0.3 watts. LED indicator for power-on Type:\nClocked. Technology: constant voltage Mounting type: DIN rail power supply.\nModel: HDR Series No-load power: 0.3 watts. Power On\/Off: LED indicator\nOperating temperature range: -30°C to +70°C. Voltage input AC: 85 - 264 V AC.\nVoltage input DC: 120 - 370 V DC. Mains frequency: 50\/60Hz Voltage: output\nvoltage | 24 VDC. Adjustable voltage: adjustable | from 21.6 V to 29 VDC.\nCurrent: output current: 1.5 A\/1500 mA. Power: output power | 36 watts\nEfficiency: 89%. Inrush current: 45 A. Dimmable: no. Overload protection: yes.\nOverload protection in %: 105 - 160%. Surge Protection: Yes Short circuit\nresistant: yes. Temperature monitoring: yes. Insulation class: II. Insulation\nvoltage: 3000V AC. Protection class: IP42. Installation area: indoor Colour:\nanthracite. Material: plastic. Length: 90 mm. Width: 35 mm \/ 2TE Height: 58.4\nmm. Power connection: screw terminals. Output connection: screw terminals.\nManufacturer: Mean Well. Manufacturer number: HDR-30-24. Package weight: 120\ng. Certification: TÜV, CE, CB, UL, LPS. RoHS: compliant\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eOutput voltage: 24 VDC\u003c\/li\u003e\n \u003cli\u003eOutput current: 1.5 A \/ 1500 mA\u003c\/li\u003e\n \u003cli\u003eOutput power: 36 watts\u003c\/li\u003e\n \u003cli\u003eConstant Voltage\u003c\/li\u003e\n \u003cli\u003eAdjustable | from 21.6 V to 29 VDC\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-09-26T01:08:21+10:00","created_at":"2025-09-26T01:08:18+10:00","vendor":"MEAN WELL","type":"Industrial Power Supply","tags":["industryDE_Sep2025"],"price":15800,"price_min":15800,"price_max":15800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45746972459161,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0713TLR11","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Mean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt Single","public_title":null,"options":["Default Title"],"price":15800,"weight":130,"compare_at_price":null,"inventory_management":"shopify","barcode":"9_mfn","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/de-B0713TLR11.jpg?v=1775751425","\/\/soundstores.net\/cdn\/shop\/files\/81X_qgAa02L.jpg?v=1758812900","\/\/soundstores.net\/cdn\/shop\/files\/81a5NAtXELL.jpg?v=1758812901","\/\/soundstores.net\/cdn\/shop\/files\/91Q35PYg4ML.jpg?v=1758812901","\/\/soundstores.net\/cdn\/shop\/files\/71P3nLxU6KL_ba9473af-91a0-435d-b4f3-b834050392ce.jpg?v=1758812900","\/\/soundstores.net\/cdn\/shop\/files\/81caq8iIo5L_1fd84f71-45db-492a-a852-a623753460cf.jpg?v=1758812900"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0713TLR11.jpg?v=1775751425","options":["Title"],"media":[{"alt":null,"id":34642807816345,"position":1,"preview_image":{"aspect_ratio":1.126,"height":2274,"width":2560,"src":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0713TLR11.jpg?v=1775751425"},"aspect_ratio":1.126,"height":2274,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/de-B0713TLR11.jpg?v=1775751425","width":2560},{"alt":null,"id":34642807849113,"position":2,"preview_image":{"aspect_ratio":1.435,"height":1500,"width":2152,"src":"\/\/soundstores.net\/cdn\/shop\/files\/81X_qgAa02L.jpg?v=1758812900"},"aspect_ratio":1.435,"height":1500,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/81X_qgAa02L.jpg?v=1758812900","width":2152},{"alt":null,"id":34642807881881,"position":3,"preview_image":{"aspect_ratio":1.126,"height":2274,"width":2560,"src":"\/\/soundstores.net\/cdn\/shop\/files\/81a5NAtXELL.jpg?v=1758812901"},"aspect_ratio":1.126,"height":2274,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/81a5NAtXELL.jpg?v=1758812901","width":2560},{"alt":null,"id":34642807914649,"position":4,"preview_image":{"aspect_ratio":1.126,"height":2274,"width":2560,"src":"\/\/soundstores.net\/cdn\/shop\/files\/91Q35PYg4ML.jpg?v=1758812901"},"aspect_ratio":1.126,"height":2274,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/91Q35PYg4ML.jpg?v=1758812901","width":2560},{"alt":null,"id":34642807947417,"position":5,"preview_image":{"aspect_ratio":1.435,"height":1500,"width":2152,"src":"\/\/soundstores.net\/cdn\/shop\/files\/71P3nLxU6KL_ba9473af-91a0-435d-b4f3-b834050392ce.jpg?v=1758812900"},"aspect_ratio":1.435,"height":1500,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/71P3nLxU6KL_ba9473af-91a0-435d-b4f3-b834050392ce.jpg?v=1758812900","width":2152},{"alt":null,"id":34642807980185,"position":6,"preview_image":{"aspect_ratio":1.435,"height":1500,"width":2152,"src":"\/\/soundstores.net\/cdn\/shop\/files\/81caq8iIo5L_1fd84f71-45db-492a-a852-a623753460cf.jpg?v=1758812900"},"aspect_ratio":1.435,"height":1500,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/81caq8iIo5L_1fd84f71-45db-492a-a852-a623753460cf.jpg?v=1758812900","width":2152}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eMean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSingle-phase MEANWELL switching power supply series HDR-30, primarily clocked\nfor DIN rail mounting in plastic housing. Can be mounted directly on the DIN\nrail. Closed design, touch-protected screw connections. Universal input.\nOverload protection thanks to current limitation, auto recovery. Protected\nagainst short circuit, overload, overvoltage. Compact size: 2 TE (DIN\nEN43880). Low idle power of only 0.3 watts. LED indicator for power-on Type:\nClocked. Technology: constant voltage Mounting type: DIN rail power supply.\nModel: HDR Series No-load power: 0.3 watts. Power On\/Off: LED indicator\nOperating temperature range: -30°C to +70°C. Voltage input AC: 85 - 264 V AC.\nVoltage input DC: 120 - 370 V DC. Mains frequency: 50\/60Hz Voltage: output\nvoltage | 24 VDC. Adjustable voltage: adjustable | from 21.6 V to 29 VDC.\nCurrent: output current: 1.5 A\/1500 mA. Power: output power | 36 watts\nEfficiency: 89%. Inrush current: 45 A. Dimmable: no. Overload protection: yes.\nOverload protection in %: 105 - 160%. Surge Protection: Yes Short circuit\nresistant: yes. Temperature monitoring: yes. Insulation class: II. Insulation\nvoltage: 3000V AC. Protection class: IP42. Installation area: indoor Colour:\nanthracite. Material: plastic. Length: 90 mm. Width: 35 mm \/ 2TE Height: 58.4\nmm. Power connection: screw terminals. Output connection: screw terminals.\nManufacturer: Mean Well. Manufacturer number: HDR-30-24. Package weight: 120\ng. Certification: TÜV, CE, CB, UL, LPS. RoHS: compliant\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eOutput voltage: 24 VDC\u003c\/li\u003e\n \u003cli\u003eOutput current: 1.5 A \/ 1500 mA\u003c\/li\u003e\n \u003cli\u003eOutput power: 36 watts\u003c\/li\u003e\n \u003cli\u003eConstant Voltage\u003c\/li\u003e\n \u003cli\u003eAdjustable | from 21.6 V to 29 VDC\u003c\/li\u003e\n \u003c\/ul\u003e"}
