{"id":8020589412505,"title":"OdiySurveil(TM) 4-Port 10\/100M IEEE802.3at (Power-in) to IEEE802.3af (Power-Out) PoE Extender for Ethernet\/PoE Power","handle":"odiysurveiltm-4-port-10-100m-ieee802-3at-power-in-to-ieee802-3af-power-out-poe-extender-for-ethernet-poe-power","description":"\u003ch3\u003eOdiySurveil(TM) 4-Port 10\/100M IEEE802.3at (Power-in) to IEEE802.3af (Power-Out) PoE Extender for Ethernet\/PoE Power\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: -Comply with IEEE 802.3af Power over Ethernet; -10\/100M Supported;\n-Extender the range of PoE an additional 120 meters; -Automatically detects\nand protects PoE equipments from being damaged by incorrect installation;\n-Plug-and Play no configuration required; -4Port PoE extender can forward both\nethernet and PoE power for 4 terminal equipment via Cat5 UTP cable. Product\nReview: 4-Ports PoE Extender has 5 10\/100M PoE ports,among them,1port for\npower input,and others for power output. Comply with 10\/100BASE-\nTX,IEEE802.3at(power-in)\/IEEE802.3af(power-out). The power input is 25.5W in\ntotal;Power output for single port is 15.4W(MAX). PoE Extenders can increase\nthe transmission distance for Ethernet data and PoE power up to 120m via Cat5\nUTP cables. It offers you great flexibility to extand the distance of PoE.\nOther Specification: Port Description: PoE input-1 RJ45 port, PoE output: 4\nRJ45 port; Network Medium: Cat5 or better UTP cables (less than 120m);\nRepeater Mode: Store and forward; MAC Address Table: 2K; Packet Buffer Memory:\n48 Byte; Switching Capacity: 400Mbps; PoE Standard: IEEE 802.3at (power-\nin),IEEE 802.3 af(power-out) ; PoE Port Power: input power-25.5Watts,output\npower-24Watts; PoE Power Supply Type:1\/2(+),3\/6(-),Mode A,End-Span; Network\nProtocol: IEEE 802.3i-10BASE-T, IEEE 802.3u: 100BASE-TX, IEEE 802.3x-Flow\nControl, IEEE 802.3af-Power over Ethernet; Regulation Compliance: FCC Part\n15B, ROHS Directive 2011\/65\/EU,Low Voltage Directive 2014\/35\/EU,EMC Directive\n2004\/108\/EC; Working Temperature: 0°C~40°C,Working Humidity: 10%~90%,No\nCondensation,Storage Temperature: -30°C~70°C,Storage Humidity: 5%~90%, No\nCondensation; Dimension:1059328.5mm. Note: To prevent the water seeping into\nthe extender,please keep PoE extender away wet environment. Package Include:\n1x 4-Port 10\/100M PoE Extender\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSE PROPERLY: This product is only used for network equipment with PoE signal function, as relay equipment to achieve signal extension. the total output power is 25.5w and the maximum output of each channel of 4 ports is 15.4W, each single port cannot be provided 15.4W at the same time. When using, the total output power of 4 ports should be less than 25.5w.\u003c\/li\u003e\n \u003cli\u003eApplicable Range: A Used with AP, IP camera, IP telephone and the other network equipments in the situation of the lack of power line or far away from the power outlets. A Installed at hotels, schools, buildings,etc.When using and installing, please strictly follow the product power and related electrical parameters, and follow the product instructions.\u003c\/li\u003e\n \u003cli\u003ePoE Standard: IEEE 802.3at (power-in),IEEE 802.3af(power-out);PoE Port Power: input power-25.5Watts,output power-24Watts;PoE Power Supply Type:1\/2(+),3\/6(-),Mode A,End-Span;\u003c\/li\u003e\n \u003cli\u003eNOTE: 1. Using high quality transmission cable which can transmit up to 100~120m,if using poor cable that will not reach to 80meters. 2.If the power consumption in front end device is too large, its working voltage may not be enough. 3.Cascading series too much, the voltage will be low, it also may not work. 4.Need to match with Poe switches as the last image.Strictly refer to poe extender Manual Guide to install the equipment,that will perfectly meet with your project requirement .\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2024-05-07T12:41:06+10:00","created_at":"2024-05-07T12:41:14+10:00","vendor":"OdiySurveil","type":"Video Transmission Systems","tags":["electronics_best_sellers_May2024"],"price":20300,"price_min":20300,"price_max":20300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44289019969689,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0198H6EUK","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"OdiySurveil(TM) 4-Port 10\/100M IEEE802.3at (Power-in) to IEEE802.3af (Power-Out) PoE Extender for Ethernet\/PoE Power","public_title":null,"options":["Default Title"],"price":20300,"weight":227,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/B0198H6EUK.jpg?v=1715095408","\/\/soundstores.net\/cdn\/shop\/files\/51giRwwFALL.jpg?v=1715049674","\/\/soundstores.net\/cdn\/shop\/files\/61SRZuOnlzL.jpg?v=1715049674","\/\/soundstores.net\/cdn\/shop\/files\/61dryPEzNkL.jpg?v=1715049674","\/\/soundstores.net\/cdn\/shop\/files\/61oTWiGm1uL.jpg?v=1715049674","\/\/soundstores.net\/cdn\/shop\/files\/61YMWK-AxBL.jpg?v=1715049674"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/B0198H6EUK.jpg?v=1715095408","options":["Title"],"media":[{"alt":null,"id":30941843816601,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/soundstores.net\/cdn\/shop\/files\/B0198H6EUK.jpg?v=1715095408"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/B0198H6EUK.jpg?v=1715095408","width":1500},{"alt":null,"id":30937570738329,"position":2,"preview_image":{"aspect_ratio":1.504,"height":681,"width":1024,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51giRwwFALL.jpg?v=1715049674"},"aspect_ratio":1.504,"height":681,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51giRwwFALL.jpg?v=1715049674","width":1024},{"alt":null,"id":30937570771097,"position":3,"preview_image":{"aspect_ratio":1.1,"height":1000,"width":1100,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61SRZuOnlzL.jpg?v=1715049674"},"aspect_ratio":1.1,"height":1000,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61SRZuOnlzL.jpg?v=1715049674","width":1100},{"alt":null,"id":30937570803865,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61dryPEzNkL.jpg?v=1715049674"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61dryPEzNkL.jpg?v=1715049674","width":1200},{"alt":null,"id":30937570836633,"position":5,"preview_image":{"aspect_ratio":1.2,"height":853,"width":1024,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61oTWiGm1uL.jpg?v=1715049674"},"aspect_ratio":1.2,"height":853,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61oTWiGm1uL.jpg?v=1715049674","width":1024},{"alt":null,"id":30937570869401,"position":6,"preview_image":{"aspect_ratio":1.337,"height":374,"width":500,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61YMWK-AxBL.jpg?v=1715049674"},"aspect_ratio":1.337,"height":374,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61YMWK-AxBL.jpg?v=1715049674","width":500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eOdiySurveil(TM) 4-Port 10\/100M IEEE802.3at (Power-in) to IEEE802.3af (Power-Out) PoE Extender for Ethernet\/PoE Power\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: -Comply with IEEE 802.3af Power over Ethernet; -10\/100M Supported;\n-Extender the range of PoE an additional 120 meters; -Automatically detects\nand protects PoE equipments from being damaged by incorrect installation;\n-Plug-and Play no configuration required; -4Port PoE extender can forward both\nethernet and PoE power for 4 terminal equipment via Cat5 UTP cable. Product\nReview: 4-Ports PoE Extender has 5 10\/100M PoE ports,among them,1port for\npower input,and others for power output. Comply with 10\/100BASE-\nTX,IEEE802.3at(power-in)\/IEEE802.3af(power-out). The power input is 25.5W in\ntotal;Power output for single port is 15.4W(MAX). PoE Extenders can increase\nthe transmission distance for Ethernet data and PoE power up to 120m via Cat5\nUTP cables. It offers you great flexibility to extand the distance of PoE.\nOther Specification: Port Description: PoE input-1 RJ45 port, PoE output: 4\nRJ45 port; Network Medium: Cat5 or better UTP cables (less than 120m);\nRepeater Mode: Store and forward; MAC Address Table: 2K; Packet Buffer Memory:\n48 Byte; Switching Capacity: 400Mbps; PoE Standard: IEEE 802.3at (power-\nin),IEEE 802.3 af(power-out) ; PoE Port Power: input power-25.5Watts,output\npower-24Watts; PoE Power Supply Type:1\/2(+),3\/6(-),Mode A,End-Span; Network\nProtocol: IEEE 802.3i-10BASE-T, IEEE 802.3u: 100BASE-TX, IEEE 802.3x-Flow\nControl, IEEE 802.3af-Power over Ethernet; Regulation Compliance: FCC Part\n15B, ROHS Directive 2011\/65\/EU,Low Voltage Directive 2014\/35\/EU,EMC Directive\n2004\/108\/EC; Working Temperature: 0°C~40°C,Working Humidity: 10%~90%,No\nCondensation,Storage Temperature: -30°C~70°C,Storage Humidity: 5%~90%, No\nCondensation; Dimension:1059328.5mm. Note: To prevent the water seeping into\nthe extender,please keep PoE extender away wet environment. Package Include:\n1x 4-Port 10\/100M PoE Extender\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSE PROPERLY: This product is only used for network equipment with PoE signal function, as relay equipment to achieve signal extension. the total output power is 25.5w and the maximum output of each channel of 4 ports is 15.4W, each single port cannot be provided 15.4W at the same time. When using, the total output power of 4 ports should be less than 25.5w.\u003c\/li\u003e\n \u003cli\u003eApplicable Range: A Used with AP, IP camera, IP telephone and the other network equipments in the situation of the lack of power line or far away from the power outlets. A Installed at hotels, schools, buildings,etc.When using and installing, please strictly follow the product power and related electrical parameters, and follow the product instructions.\u003c\/li\u003e\n \u003cli\u003ePoE Standard: IEEE 802.3at (power-in),IEEE 802.3af(power-out);PoE Port Power: input power-25.5Watts,output power-24Watts;PoE Power Supply Type:1\/2(+),3\/6(-),Mode A,End-Span;\u003c\/li\u003e\n \u003cli\u003eNOTE: 1. Using high quality transmission cable which can transmit up to 100~120m,if using poor cable that will not reach to 80meters. 2.If the power consumption in front end device is too large, its working voltage may not be enough. 3.Cascading series too much, the voltage will be low, it also may not work. 4.Need to match with Poe switches as the last image.Strictly refer to poe extender Manual Guide to install the equipment,that will perfectly meet with your project requirement .\u003c\/li\u003e\n \u003c\/ul\u003e"}
