{"id":8715289362585,"title":"UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection","handle":"uotek-utek-ut-890-tc-usb-type-c-to-rs-485-422-serial-converter-with-esd-protection","description":"\u003ch3\u003eUOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e1. Standards: conforming to USBV1.1 2.0and 3.1, EIA RS-485 and RS-422,\r\nbackwards compatible. 2. USB signals: VCC DATA+ DATA- GND FG 3. RS-485\r\nsignals: T\/R+, T\/R-, GND. 4. RS-422 signals: T\/R+, T\/R-, R+, R-, GND. 5.\r\nWorking modes: asynchronous, point-to-point or point-to-multipoint, 2-line\r\nhalf duplex and 4-line full duplex. 6. Direction control: adoption of\r\nautomatic data stream control for automatic recognition and control of data\r\ntransmission direction. 7. Baud rate: 300-921.6Kbps, automatic detection of\r\nthe transmission rate of the serial interface signal. 8. Workload ability:\r\npoint-to-multipoint supported, a maximum of 32 RS-422 or RS-485 interface\r\nequipments are supported. 9. Transmission distance: 1200 meters for RS-485\/422\r\nend (when 9,600bps) and a maximum of 5 meters for USB. 10. Interface\r\nprotection: 600W lightning strike and surge protection and ±5KV electrostatic\r\nprotection. 11. Interface forms: USB terminal class C interface male head, DB9\r\nmale connector 12. Signal indication: 3 indicator lights for Power (PWR), Send\r\n(TXD) and Receive (RXD). 13. Transmission media: twisted-pair cable or\r\nshielded cable. 14. Transmission rate: 128,000bps to 300M. 38,400bps to 600M.\r\n9,600bps to 1200M. communication modes: 1. Point-to-point 4-line full duplex\r\n2. Point-to-multipoint 4-line full duplex 3. Point-to-point 2-line half duplex\r\n4. Point-to-multipoint 2-line half duplex\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eStandards: USB V1.1, 1.0, 2.0, 3.1, RS-485\/RS-422 EIA USB signal: VCC, DATA+, DATA-, GND, FG RS-485 signal: T\/R+, T\/R-, GND RS-422 signal: T\/R+, T\/R-, RXD+, RXD-, GND Industrial environment\u003c\/li\u003e\r\n \u003cli\u003eWorking mode: Asynchronous, point to point or point to multi-point, 2-wire half duplex, 4-wire full duplex Direction control: Adopts flow direction auto-control technology, auto identify and control the flow transmission direction Baud rate: 300-921,600bps\u003c\/li\u003e\r\n \u003cli\u003eLoad capcity: Supports point to multi-point, allows to connect up to 32 sets RS-422 or RS-485 device Transmission distance: RS-485\/422 1,200m(9600bps), USB no more than 5m Port protection: 600W surge, 15KV ESD protection Connector: USB-C male, DB9 male Signal: TXD, RXD\u003c\/li\u003e\r\n \u003cli\u003eTransmission media: Twisted-pair or shielded wire Baud rate: 921,600bps 300M 38,400bps 600M 9,600bps 1.2KM Dimension: 55mmX36mmX18mm\u003c\/li\u003e\r\n \u003cli\u003eWorking temperature: -40C to 85C Relative humidity: 5% to 95% Supports Win2000\/2003\/2008\/2012\/XP\/Vista\/7\/8\/8.1\/10\/CE\/Mac\/Linux\u003c\/li\u003e\r\n \u003cli\u003eLED Indicators, High-Speed Data Transfer USB-C Industry application\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2026-04-20T09:43:35+10:00","created_at":"2026-04-20T09:43:32+10:00","vendor":"UOTEK","type":"Serial Adapters","tags":["sound_Apr2026"],"price":13300,"price_min":13300,"price_max":13300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":46972910305433,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B073WZY9L3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection","public_title":null,"options":["Default Title"],"price":13300,"weight":136,"compare_at_price":null,"inventory_management":"shopify","barcode":"799418889030","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/soundstores.net\/cdn\/shop\/files\/B073WZY9L3.jpg?v=1776698348","\/\/soundstores.net\/cdn\/shop\/files\/41Nh3vJdPiL.jpg?v=1776642214","\/\/soundstores.net\/cdn\/shop\/files\/41ni41n2ciL.jpg?v=1776642214","\/\/soundstores.net\/cdn\/shop\/files\/51eTZ5GFAOL.jpg?v=1776642214","\/\/soundstores.net\/cdn\/shop\/files\/61mub2tEMjL.jpg?v=1776642214","\/\/soundstores.net\/cdn\/shop\/files\/41ya8Hvy2TL.jpg?v=1776642214","\/\/soundstores.net\/cdn\/shop\/files\/61RaDoXAQwL.jpg?v=1776642214"],"featured_image":"\/\/soundstores.net\/cdn\/shop\/files\/B073WZY9L3.jpg?v=1776698348","options":["Title"],"media":[{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613395097,"position":1,"preview_image":{"aspect_ratio":0.768,"height":2040,"width":1566,"src":"\/\/soundstores.net\/cdn\/shop\/files\/B073WZY9L3.jpg?v=1776698348"},"aspect_ratio":0.768,"height":2040,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/B073WZY9L3.jpg?v=1776698348","width":1566},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613427865,"position":2,"preview_image":{"aspect_ratio":0.768,"height":1020,"width":783,"src":"\/\/soundstores.net\/cdn\/shop\/files\/41Nh3vJdPiL.jpg?v=1776642214"},"aspect_ratio":0.768,"height":1020,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/41Nh3vJdPiL.jpg?v=1776642214","width":783},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613460633,"position":3,"preview_image":{"aspect_ratio":0.768,"height":1020,"width":783,"src":"\/\/soundstores.net\/cdn\/shop\/files\/41ni41n2ciL.jpg?v=1776642214"},"aspect_ratio":0.768,"height":1020,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/41ni41n2ciL.jpg?v=1776642214","width":783},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613493401,"position":4,"preview_image":{"aspect_ratio":0.768,"height":1020,"width":783,"src":"\/\/soundstores.net\/cdn\/shop\/files\/51eTZ5GFAOL.jpg?v=1776642214"},"aspect_ratio":0.768,"height":1020,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/51eTZ5GFAOL.jpg?v=1776642214","width":783},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613526169,"position":5,"preview_image":{"aspect_ratio":0.788,"height":1020,"width":804,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61mub2tEMjL.jpg?v=1776642214"},"aspect_ratio":0.788,"height":1020,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61mub2tEMjL.jpg?v=1776642214","width":804},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613558937,"position":6,"preview_image":{"aspect_ratio":1.266,"height":395,"width":500,"src":"\/\/soundstores.net\/cdn\/shop\/files\/41ya8Hvy2TL.jpg?v=1776642214"},"aspect_ratio":1.266,"height":395,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/41ya8Hvy2TL.jpg?v=1776642214","width":500},{"alt":"[AUSTRALIA] - UOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection ","id":36239613591705,"position":7,"preview_image":{"aspect_ratio":0.835,"height":1167,"width":975,"src":"\/\/soundstores.net\/cdn\/shop\/files\/61RaDoXAQwL.jpg?v=1776642214"},"aspect_ratio":0.835,"height":1167,"media_type":"image","src":"\/\/soundstores.net\/cdn\/shop\/files\/61RaDoXAQwL.jpg?v=1776642214","width":975}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eUOTEK UTEK UT-890-TC USB Type-C to RS-485\/422 Serial Converter with ESD Protection\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e1. Standards: conforming to USBV1.1 2.0and 3.1, EIA RS-485 and RS-422,\r\nbackwards compatible. 2. USB signals: VCC DATA+ DATA- GND FG 3. RS-485\r\nsignals: T\/R+, T\/R-, GND. 4. RS-422 signals: T\/R+, T\/R-, R+, R-, GND. 5.\r\nWorking modes: asynchronous, point-to-point or point-to-multipoint, 2-line\r\nhalf duplex and 4-line full duplex. 6. Direction control: adoption of\r\nautomatic data stream control for automatic recognition and control of data\r\ntransmission direction. 7. Baud rate: 300-921.6Kbps, automatic detection of\r\nthe transmission rate of the serial interface signal. 8. Workload ability:\r\npoint-to-multipoint supported, a maximum of 32 RS-422 or RS-485 interface\r\nequipments are supported. 9. Transmission distance: 1200 meters for RS-485\/422\r\nend (when 9,600bps) and a maximum of 5 meters for USB. 10. Interface\r\nprotection: 600W lightning strike and surge protection and ±5KV electrostatic\r\nprotection. 11. Interface forms: USB terminal class C interface male head, DB9\r\nmale connector 12. Signal indication: 3 indicator lights for Power (PWR), Send\r\n(TXD) and Receive (RXD). 13. Transmission media: twisted-pair cable or\r\nshielded cable. 14. Transmission rate: 128,000bps to 300M. 38,400bps to 600M.\r\n9,600bps to 1200M. communication modes: 1. Point-to-point 4-line full duplex\r\n2. Point-to-multipoint 4-line full duplex 3. Point-to-point 2-line half duplex\r\n4. Point-to-multipoint 2-line half duplex\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eStandards: USB V1.1, 1.0, 2.0, 3.1, RS-485\/RS-422 EIA USB signal: VCC, DATA+, DATA-, GND, FG RS-485 signal: T\/R+, T\/R-, GND RS-422 signal: T\/R+, T\/R-, RXD+, RXD-, GND Industrial environment\u003c\/li\u003e\r\n \u003cli\u003eWorking mode: Asynchronous, point to point or point to multi-point, 2-wire half duplex, 4-wire full duplex Direction control: Adopts flow direction auto-control technology, auto identify and control the flow transmission direction Baud rate: 300-921,600bps\u003c\/li\u003e\r\n \u003cli\u003eLoad capcity: Supports point to multi-point, allows to connect up to 32 sets RS-422 or RS-485 device Transmission distance: RS-485\/422 1,200m(9600bps), USB no more than 5m Port protection: 600W surge, 15KV ESD protection Connector: USB-C male, DB9 male Signal: TXD, RXD\u003c\/li\u003e\r\n \u003cli\u003eTransmission media: Twisted-pair or shielded wire Baud rate: 921,600bps 300M 38,400bps 600M 9,600bps 1.2KM Dimension: 55mmX36mmX18mm\u003c\/li\u003e\r\n \u003cli\u003eWorking temperature: -40C to 85C Relative humidity: 5% to 95% Supports Win2000\/2003\/2008\/2012\/XP\/Vista\/7\/8\/8.1\/10\/CE\/Mac\/Linux\u003c\/li\u003e\r\n \u003cli\u003eLED Indicators, High-Speed Data Transfer USB-C Industry application\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
